3D-Silent-Gamer-PC G9 i9 14900K 24-Core, 128 GB DDR5, RTX 5090 32GB, 4.0TB SSD, 1300 Watt Gold, Win11-Pro

 Prozessor:

• INTEL Core i9-14900K "Raptor Lake-S", 24x 3.2GHz (max. 6.0GHz) Sockel 1700, 24x (Boost: 3.2GHz), 6.0GHz
  36MB L2 Cache, 36MB L3 Cache, max. TDP: 125W • IGP: Intel UHD Graphics 770, Intel 64 (64-Bit), VT-x
  HyperThreading, Turbo Boost Max 3.0, ECC-Unterstützung

Mainboard:

• GIGABYTE Z790 AORUS ELITE AX
  Intel Z790, Dual Channel DDR5 • 3x PCIe 5.0 x16/PCIe 4.0 x16 (CrossFire), • 6x SATA 6Gb/s
  LAN: 1x 2.5 GBit, WLAN: 802.11 a/b/g/n/ac/ax • 4x USB 2.0, 3x USB 3.0 (USB 3.2 Gen 1)
  2x USB 3.1 (USB 3.2 Gen 2), 1x USB-C 3.2 (USB 3.2 Gen 2x2) • ATX • Bluetooth 5.3

Chipsatz:

• Intel® Z790

Gehäuse:

• be quiet! PC-Gehäuse Pure Base 500 FX Schwarz: Anschlüsse vorne: 2 x USB 3.0, 1x 1x USB-C 3.2
  Gaming Mid Tower mit RGB Beleuchtung
  Das be quiet! Pure Base 500 FX Black bietet beeindruckende Beleuchtung mit vielzähligen Effekten
  und maximalen Airflow für höchste Performance und Kühlung.

Wasserkühlung:

•  be quiet! PURE LOOP 280 mm, Wasserkühlung PURE LOOP 280 mm
  Geräuschentwicklung in Betrieb: 38.1 dBA
  Doppelt entkoppelte Pumpe für leisen Betrieb und minimale Vibrationen
  Pure Wings 2 140 mm PWM-Lüfter kombiniert leisen Betrieb mit hohem Luftdruck
  Kombination aus weisser LED-Beleuchtung, schwarzem Design und Aluminiumstil ergibt
  ein unvergleichliches Erscheinungsbild

Arbeitsspeicher:

• Corsair 128GB DDR5-RAM Vengeance 5600 MHz (4x 32 GB)
  High-Performance Arbeitsspeicher
  Bauform: DIMM, 288 Pins
  ODECC (On-Die ECC), Latenzzeiten: CL40-40-40-77
  Spannung: 1.25 V

Grafikkarte:

• GAINWARD GeForce RTX 5090 Phantom, GeForce RTX 5090, 32GB GDDR7,PCI-Express 5.0 x16
  1x Nvidia GB202 (2.017 GHz/OC Mode: 2.407 GHz), 32GB GDDR7 (1.75 GHz/512 bit), DirectX 12
  OpenGL 4.6, aktiv gekühlt • Ausgänge: 1x HDMI, 3x DisplayPort, HDCP 2.3

SSD-Platte:

• SAMSUNG 990 PRO NVMe M.2 SSD, 4.0TB M.2 (2280), Protokoll: NVMe, NAND: TLC (3D), 2GB Cache
  lesen: 7.45 GB/s, schreiben: 6.9 GB/s, random 4KB lesen: 1400000 IOPS, random 4KB schreiben: 1550000 IOPS
  M.2 (PCIe 4.0 x4) • TCG Opal 2.0, Hardwareverschlüsselung


Audiokarte:

- Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software.
  To configure 7.1-channel audio, access the audio software for audio settings.
  Support for S/PDIF Out

Massenspeichergeräte:

1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
  2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB)
  1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB)
  6 x SATA 6Gb/s connectors
  * Refer to "2-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

RAID:

- RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
  RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices

USB:

• 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
  1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
  2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
  5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
  Chipset+2 USB 2.0 Hubs:
  8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Netzwerk:

• Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Multi-GPU:

• Unterstützt die AMD® Quad-GPU CrossFireX™-Technologie

Interne Schnitstellen:

- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
  * For optimum performance, if only one PCI Express graphics card is to be installed
  2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)
  Support for AMD CrossFire™ technology (PCIEX16 and PCIEX4)

Anschlüsse vorne:

- 1 x USB 3.0, 1 x USB 3.1
- 1 x Audio out
- 1 x Microfon in

Anschlüsse Rückseite:

- 4 x USB 2.0/1.1 ports
  2 x SMA antenna connectors (2T2R)
  2 x USB 3.2 Gen 2 Type-A ports (red)
  1 x DisplayPort
  1 x HDMI 2.0 port
  3 x USB 3.2 Gen 1 ports
  1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
  1 x RJ-45 port
  1 x optical S/PDIF Out connector
  2 x audio jacks

 Netzteil:

• Seasonic Netzteil PRIME GX 1300 W, Vollmodulares 1300W, 80 PLUS Zertifikat: 80 PLUS Gold, Vergoldete Kontakte (Motherboard, CPU und PCIe Kabel)

- 80 PLUS® Gold certified
- Micro Tolerance Load Regulation (0.5 %)
- Cable-free Connection Design
- Premium Hybrid Fan Control - Fanless until 40 % load
- Multi-GPU setup
- Gold plated connectors
- 12 years warranty


Fan Information Fan Size 135 mm
Fan Control Premium Hybrid Fan Control - fanless untli 20% load
Fan Bearing Fluid Dynamic Bearing
Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information Modularity Fully Modular
Cable type Webbed cables (MB, CPU, PCIe)
Flat black cables
Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 12 Years
Power Output
AC Input Voltage: 100 V - 240 V
Current: 15 A–7.5 A
Frequency: 50 Hz–60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 108 A 0.3 A 3 A
125 W 1296 W 3.6 W 15 W
Total continuous power 1320 W

Betriebsystem:

• Microsoft Windows 11 Pro 64 Bit, komplett vorinstalliert (inkl. neuester Treiber + 8 Stunden Stresstest)

Abmessungen:

• Tiefe 450 mm, Breite 232 mm, Höhe 463 mm

Gewicht:

• ca. 18KG

Garantie:

• 2 Jahre Garantie auf kompletten PC
